Heavy Duty Vision System with 7″ AHD Monitor

COMING SOON! Available for purchase in July Brandmotion’s Heavy Duty Vision System with 7″ AHD Monitor provides higher quality and smoother video through standard composite video connections. This system is perfect for commercial fleets, providing a crystal clear image on the 7″ digital monitor giving your drivers the maximum visibility. With the ability to equip up to 4 cameras, decrease downtime by removing blindspots, significantly reducing unwanted collisions.
Home Shop Monitors Heavy Duty Vision System with 7″ AHD Monitor

0

User feedback

Heavy Duty Vision System with 7″ AHD Monitor

COMING SOON! Available for purchase in July

Brandmotion’s Heavy Duty Vision System with 7″ AHD Monitor provides higher quality and smoother video through standard composite video connections. This system is perfect for commercial fleets, providing a crystal clear image on the 7″ digital monitor giving your drivers the maximum visibility. With the ability to equip up to 4 cameras, decrease downtime by removing blindspots, significantly reducing unwanted collisions.

Part Number:

FLTW-7000

Category:

Categories: ,

MSRP

$549.95

Purchase Options

  • 4 Inputs with Trigger Wires
  • DVR Optional (SD card not included)
  • Always On Observation
  • Heavy Duty for Increased Visibility
  • Night Vision
  • Built-In Monitor Speaker and Camera Microphone (optional)

CAMERA

Working Voltage 10v – 16v
Rated Voltage / Current 130ma
Working Temperature -20℃ to 70℃
Storage Temperature -30℃〜85℃
Connection Type 4-Pin Aviator Wired
Mounting Locations Rear or front
Mounting Type U-Bracket
Field of View (H) (V) 140º, 90º
Low Light Night Vision 0.1 LUX
Lens Size 1/4 inch
Built in IRs Yes
Waterproof Rating IP68
Video Format Output AHD
Resolution 1080p



MONITOR

Working Voltage DC12V to DC24V
Power Consumption 4W
Working Temperature -20℃-60℃
Storage Temperature -30℃-70℃
Display Brightness 500cd/m2
Screen Size 7 inch
Resolution 1024*600(IPS)
Aspect Ratio 16:9
Camera Connection Type 4-Pin Aviator Wired (Max 4 cameras)
Video Format Input AHD
DVR Built-in Y/N Yes
Built in speaker Yes
Video trigger input triggers Yes
  • Universal
